ReadyScan B Global handheld 3D measurement devices
ReadyScan B is not limited by the size, shape, material, or complexity of the object being scanned. It can freely switch between different working modes such as high-speed scanning and deep hole scanning. The device also has a built-in photogrammetry system, providing precise and efficient independent operation, with a volume accuracy of up to 0.030mm/m. ReadyScan B can quickly complete high-precision 3D inspections for medium and large objects, meeting the demands of industries such as aerospace, automotive manufacturing, mechanical manufacturing, and energy heavy industry.
-
Scanning area of up to 860 mm × 600 mm
-
Measurement accuracy up to 0.20mm
-
Scan rate 2,000,000 measurements/SEC
-
Time-labor saving for extraordinary efficiency
With 34 blue laser beams, the scanning rate can reach to 2,000,000 measurements per second, allowing for rapid acquisition of 3D data and capturing scanning details with exceptional precision.
-
Large field of view for effortless measurement
Integrated with photogrammetry function, the device provides a comprehensive and expansive scanning field of view, making it easy to handle spacious and complex conditions. It is tailored for measuring medium and large-scale objects.
-
Multiple modes for flexible scanning
Working modes are capable of freely switching based on scanning needs: efficient unrivaled-speed scanning; accurate deep hole scanning, dealing with intricate positions like deep holes and dead angles.
Parameter
Product |
ReadyScan B Series |
|
Type |
ReadyScan B11 |
ReadyScan B17 |
Laser source |
22 blue laser crosses+ 1 exra blue laser line |
34 blue laser crosses +1 exra blue laser line ) |
Deep hole scaning |
Support |
|
Accuracy(1)[mm] |
0.020 |
|
Measurement rate |
1,300,000 measurements/s |
2,000,000 measurements/s |
Scanning area [mm²] |
550 × 600 |
860 x 600 |
Scanning area (photogrammetry) [mm²] |
2500 x 3000 |
3760 x 3150 |
Photogrammetry [mm] |
2500 |
2500 |
Laser class |
Class Ⅱ(eye safe) |
|
Resolution [mm] |
0.025 |
|
volume accuracy(2 ) [mm/m] |
Standard:0.020 + 0.035Equipped with 1m high-precision benchmark:0.020+0.020Equipped with MSCAN-L15 global photogrammetry system:0.020+0.015 |
Standard:0.020 + 0.030Equipped with 1m high-precision benchmark:0.020+0.020Equipped with MSCAN-L15 global photogrammetry system:0.020+0.015 |
Reference distance[mm] |
300 |
|
Depth of field [mm] |
500 |
|
Output formats |
.stl, .ply, .obj, .igs, wrl, .xyz, .dae, .fbx, .ma, .asc,etc |
|
Operating temperature |
-10~40°C |
|
Data interface |
USB 3.0 |
(1) ISO 17025 accredited: Based on VDI/VDE 2634 Part 3 standard and JJF 1951 specification, probing error (size) (PS) performance is evaluated.
(2) ISO 17025 accredited: Based on VDI/VDE 2634 Part 3 standard and JJF 1951 specification, sphere spacing error (SD) performance is evaluated.
